EMD Model F7
The F-unit roster text by Jim Sandrin, from BRHS Bulletin #4,
THE GRAYBACKS ©1982 Burlington Route Historical Society
|
|
In May 1950, the CB&Q proper acquired its only F7's 10 A's and three B's. These units had a 36" dynamic brake fan ahead of the four radiator fans, thus differentiating them from the Phase IV F3's. Nine of the F7's were numbered as three-unit A/B/A sets 167-169, while the other four A's were 163A through 166A. |
Click on diagram to see larger size. |
|
|
|
With delivery of the F7's, the last two four-unit F3 sets were broken up and reassembled with the single F7 A-units to form three unit F3-A/F3-B/F7-A sets 163 through 166. The renumbering went as follows:
137A to 163C |
|
138A to 165C |
137B to 163B |
|
137B to 165B |
137C to 164B |
|
138C to 166B |
137D to 164C |
|
138D to 166C |
|
Click on diagram to see larger size. |
CB&Q F7 #169A in Aurora, IL, probably mid-1960s. You can see the original ABA unit below. (courtesy Jan Kohl/Castle Graphics) |
|
|
The units in these F3-F7 sets matched well. The only outwardly visible difference between them being in the rooftop dynamic brakes. From the ground, the 163-166 sets appeared identical to the "pure" F7 sets, 167-169.
In August 1950, subsidiaries Colorado & Southern and Fort Worth & Denver both acquired their first F-unitsA/B/B/A F7 sets decked out in all the stock Q options but numbered and sublettered for their owners. The C&S sets were 700 through 702, while the FW&D units were 750 through 752.
The C&S and FW&D units turned out to be the Burlington's last F-unit purchases. In 1951 the Q switched to the GP7 (two full years after its introduction!) and never bought another carbody-type unit. |
|
CB&Q
Number |
Blt. Date |
Serial # |
Description |
Disposition |
Disp.Date |
Notes |
163A |
5/50 |
9692 |
1 unit of ABA set #163 |
Traded in on SD45 |
2/69 |
6 |
164A |
5/50 |
9693 |
1 unit of ABA set #164 |
Traded in on SD45 |
2/69 |
6 |
165A |
5/50 |
9694 |
1 unit of ABA set #165 |
Traded in on SD45 |
2/69 |
6 |
166A |
5/50 |
9695 |
1 unit of ABA set #166 |
Traded in on SD45 |
2/69 |
6 |
167A |
5/50 |
9696 |
1 unit of ABA set #167 |
Traded in on SD45 |
2/69 |
|
167B |
5/50 |
9702 |
1 unit of ABA set #167 |
Traded in on SD45 |
2/69 |
|
167C |
5/50 |
9697 |
1 unit of ABA set #167 |
Traded in on SD45 |
2/69 |
|
168A |
5/50 |
9798 |
1 unit of ABA set #168 |
Traded in on SD45 |
8/70 |
9 |
168B |
5/50 |
9703 |
1 unit of ABA set #168 |
Traded in on SD45 |
1/69 |
|
168C |
5/50 |
9799 |
1 unit of ABA set #168 |
Traded in on SD45 |
8/70 |
9 |
169A |
5/50 |
9700 |
1 unit of ABA set #169 |
Traded in on SD45 |
2/69 |
|
169B |
5/50 |
9704 |
1 unit of ABA set #169 |
Traded in on SD45 |
2/69 |
8 |
169C |
5/50 |
9701 |
1 unit of ABA set #169 |
Traded in on SD45 |
2/69 |
|
C&S
Number |
Blt. Date |
Serial # |
Description |
Disposition |
Disp. Date |
Notes |
700A |
8/50 |
11317 |
1 unit of ABA set #700 |
Traded in on SD40 |
5/68 |
|
700B |
8/50 |
11323 |
1 unit of ABA set #700 |
Traded in on SD40 |
5/68 |
|
700C |
8/50 |
11324 |
1 unit of ABA set #700 |
Traded in on SD40 |
4/68 |
|
700D |
8/50 |
11318 |
1 unit of ABA set #700 |
Rebuilt to F9-Am |
3/59 |
10 |
701A |
8/50 |
11319 |
1 unit of ABA set #701 |
SFS to PECO |
4/68 |
|
701B |
8/50 |
11325 |
1 unit of ABA set #701 |
SFS to PECO |
4/68 |
|
701C |
8/50 |
11326 |
1 unit of ABA set #701 |
Traded in on U30C |
7/68 |
|
701D |
8/50 |
11320 |
1 unit of ABA set #701 |
Traded in on U30C |
5/68 |
|
702A |
8/50 |
11321 |
1 unit of ABA set #702 |
Traded in on SD40 |
5/68 |
|
702B |
8/50 |
11327 |
1 unit of ABA set #702 |
Traded in on SD40 |
5/68 |
|
702C |
8/50 |
11328 |
1 unit of ABA set #702 |
Traded in on SD40 |
5/68 |
|
702D |
8/50 |
11322 |
1 unit of ABA set #702 |
Traded in on U30C |
7/68 |
|
FW&D
Number |
Blt. Date |
Serial # |
Description |
Disposition |
Disp. Date |
Notes |
750A |
8/50 |
11329 |
1 unit of ABA set #750 |
Rebuilt to F9-Am |
3/59 |
11 |
750B |
8/50 |
11335 |
1 unit of ABA set #750 |
Traded in on SD40 |
5/68 |
|
750C |
8/50 |
11336 |
1 unit of ABA set #750 |
Traded in on U30C |
8/68 |
|
750D |
8/50 |
11330 |
1 unit of ABA set #750 |
Traded in on SD40 |
5/68 |
|
751A |
8/50 |
11331 |
1 unit of ABA set #751 |
Traded in on U30C |
8/68 |
|
751B |
8/50 |
11337 |
1 unit of ABA set #751 |
Traded in on U30C |
8/68 |
|
751C |
8/50 |
11338 |
1 unit of ABA set #751 |
Traded in on U30C |
8/69 |
|
751D |
8/50 |
11332 |
1 unit of ABA set #751 |
Traded in on U30C |
8/70 |
|
752A |
8/50 |
11333 |
1 unit of ABA set #752 |
Traded in on SD40 |
5/68 |
|
752B |
8/50 |
11339 |
1 unit of ABA set #752 |
Traded in on U30C |
8/68 |
|
752C |
8/50 |
11340 |
1 unit of ABA set #752 |
Traded in on SD40 |
5/68 |
|
752D |
8/50 |
11334 |
1 unit of ABA set #752 |
Traded in on SD40 |
5/68 |
|
Footnotes |
|
|
6. F-3 number series 137 through 138 were broken up and renumbered in 1950 and combined with 4 F-7's to produce F-3-7 series 163 through 166. The F-3 series 137, for example, became F-3-7 163, using an F7 (later renumbered 163A) and F-3 137 (using the ''A" and " B" units), and F-3-7 164, using an F-7 and F-3 137 ("C" and "D" ), and so on.
8. Modified with a square hostler window and controls added |
|
9. 168A and 168C made it into the BN era. 168A was assigned BN #796, but still carried it's Q number when traded in 5 months after the merger.
10. 700D was destroyed in a wreck at Broomfield, CO on 9/22/58. The unit was then sent to EMD where it was rebuilt to an F9-Am in 3/59.
11. 750A was destroyed in a wreck at Chugwater, WY on 9/17/58. The unit was then sent to EMD where it was rebuilt to an F9-Am in 3/59. |
|
